Tantalum Niobium Alloy Qws

1.Catalog No.:TA0020
2.Material:R05240 (Ta-40Nb)
3.Purity：>=99.9 feem pua lossis 99.95 feem pua
4.Size Diameter: 1 nti ~ 8 nti, Ntev: <10 feet
5. Txuj: ASTM B365

Xa kev nug

Khoom Taw qhia

Raws li koj cov specifications, peb tsim thiab tshuab cov khoom ua los ntawm tantalum niobium alloy.Raws li koj specifications, Yusheng Materials Technology muaj zoo li tus thiab machined tantalum niobium alloy khoom.

Yusheng Hlau yog tus neeg muag khoom ntseeg siab thiab tsim khoom ntawm Tantalum Niobium Alloy Qws, Tantalum Niobium Bar, nrog rau ntau yam khoom ntawm tantalum niobium.

Lwm cov ntaub ntawv suav nrog Ta-Nb daim ntawv lossis lub rooj tsavxwm, Ta-Nb ntawv ci lossis sawb, Ta-Nb hlau, thiab lwm yam.

Tantalum Qws thiab Bar, nrog rau Tantalum Tungsten Alloy Qws thiab Bar, yog cov khoom muaj feem xyuam.

I. Tantalum Niobium Qws piav qhia

Tantalum muaj kev tiv thaiv zoo rau acid corrosion thiab yog ductile. Nws yog ib tug zoo tshav kub thiab hluav taws xob conductor nrog ib tug siab melting point.Rau daim ntaub ntawv uas yuav tsum tau tshav kub-resistant thiab combustion khoom, niobium, kuj hu ua columbium, feem ntau alloyed nrog tantalum.

II. Tantalum Niobium Qws Specification

Khoom	Qws thiab bar ua los ntawm tantalum-niobium alloy
Loj	Txoj kab uas hla: 1 nti ~ 8 nti Ntev:< 10 feet
Khoom siv	R05240 (Ta-40Nb)
Txuj	ASTM B 365 Cov Lus Qhia Tshwj Xeeb
Purity	>99.95 feem pua lossis 99.9 feem pua

III.Chemical Composition

Element	R05240 (Ta-40Nb) (%)
C	0.01
O	0.02
N	0.01
H	0.0015
Fe	0.01
Mo	0.02
Nb	35.0–42.0
Ni	0.01
Si	0.005
Ti	0.01
W	0.05

Tantalum thiab Tantalum Alloy

R05200, Unalloyed tantalum, lub tshuab nqus tsev-arc yaj, los yog ob qho tib si, tsim siv lub tshuab hluav taws xob hluav taws xob

R05400, unalloyed tantalum, hmoov-metallurgy consolidation.

R05255, Ta-W alloy, 90% tantalum, 10% tungsten, electron-beam rauv ntawm lub tshuab nqus tsev-arc yaj, los yog ob qho tib si.

R05252, Ta-W alloy, 97.5% tantalum, 2.5% tungsten, electron-beam rauv los yog nqus-arc yaj, los yog ob qho tib si.

R05240, Ta-Nb alloy, 60 feem pua tantalum, 40 feem pua niobium, electron-beam rauv los yog nqus-arc yaj.

IV.Tantalum Niobium Alloy Qws Daim Ntawv Thov

siv nyob rau hauv kev tsim cov khoom siv hluav taws xob rau cov xov tooj, pagers, tus kheej lub computer, thiab nws pib electronics.

Siv los ua cov cuab yeej carbide.

Tantalum Niobium Alloy Rod

V. Tantalum Niobium Alloy Qws Ntim

Peb cov khoom Tantalum Niobium qws tau ua tib zoo saib xyuas kom tsis txhob muaj kev puas tsuaj thaum lub sijhawm khaws cia thiab kev thauj mus los thiab khaws cia zoo ntawm peb cov khoom hauv lawv qhov qub.

VI.Lwm yam Tantalum niobium alloy khoom:

Crucibles, bolts, cua sov ntsiab lus, thaiv cov ntxaij vab tshaus, thiab lwm yam khoom ua los ntawm tantalum niobium alloy.

Cov tshuaj muaj pes tsawg leeg ntawm txhua qib tantalum-niobium alloy.

Kev piav qhia
	Cov ntsiab lus tseem ceeb (%)		Impurities (feem pua, siab tshaj)
	Ta	Nb	Fe	Si	Ni	W	Mo	Ti	O	C	H	N
Taub 3	Nco ntsoov	2.5~3.5	0.005	0.005	0.004	0.005	0.005	0.004	0.012	0.005	0.0015	0.005
TAB 20	Nco ntsoov	17.0~23	0.005	0.005	0.004	0.005	0.005	0.004	0.012	0.005	0.0015	0.005
TAB 30	Nco ntsoov	27.0~33	0.005	0.004	0.003	0.004	0.004	0.003	0.012	0.004	0.0015	0.004
TAB 40	Nco ntsoov	37.0~43	0.005	0.004	0.003	0.004	0.004	0.003	0.012	0.004	0.0015	0.004

Tantalum niobium alloy equipment

FAQ
Q: Thaum twg kuv yuav tau txais kuv cov lus hais?
A: Peb nkag siab tias kev lag luam nrawm nrawm npaum li cas hnub no. Tsis pub dhau 24 teev tom qab tau txais koj qhov kev thov, peb cia siab tias yuav muab cov lus qhia rau koj. Los ntawm kev zam cov ntawv luam tawm, qhia cov nqi yuav khoom, thiab tshwj xeeb txog cov khoom sib xyaw hauv koj qhov kev thov, koj tuaj yeem ua kom cov txheej txheem no nrawm dua.
